Heavy-Duty Alko Towball for Secure Towing | Durable & Reliable

0 out of 5

$106.40

Alko’s special 50mm towball is designed to be used with their stabiliser coupling.

These are made to suit the aks coupling and need to either be used with the alko retention plate or some other device to prevent the ball from rotating when the coupling is clamped on.

Do not grease this ball.

Description

Alko AKS Stabiliser 50mm 3.5t towball.

*Adaptor plate not included.

The AL­KO “AKS” range of stabilizing coupling heads is fitted as original equipment on most European caravans
and some Australian and New Zealand caravans as optional equipment, where a 50mm towball is used.
The effective suppression of snaking movements of the caravan or trailer is achieved by 4 special friction pads
which surround the towball and resist rotation.
AS A RESULT OF THIS DESIGN IT IS IMPERATIVE THAT THE 50mm TOWBALL USED ON THE TOWING
THE VEHICLE IS UNABLE TO BE LOOSENED BY ROTATION.
Most tow vehicles within Europe use a rigid forged 50mm towball which is bolted to an attachment on the
vehicle towbar. The fixing and retention of this style of towball are not affected by the friction clamping of the AKS
style stabiliser.
However, most tow vehicles within Australia and New Zealand use a conventional towball which is most
commonly fixed through the towbar tongue and retained by a washer and nut. This type of towball, when used in
conjunction with an AKS style coupling head could become loosened by normal vehicle/caravan rotation during
turning.
To eliminate this AL­KO has developed, using an Australian Standard 50mm towball (with flats on the ball
flange), a retention plate that stops the rotation of the towball during operation.

Additional information

Weight 1.12 kg
Dimensions 14 × 6 × 6 cm
Brand

AL-KO

Capacity

3500Kg

Thread

7/8"

Tow Ball Size

50mm

Capacity

3500Kg

  • Suits: ALKO AKS2000
  • Colour: Black
  • Towing Capacity: 3500kg
  • Ball Dimension: 50mm (standard)
  • Shipping Weight: 1.1kg
  • Note 1: not recommended to grease this ball
  • Note 2: Must be used with the Alko Retention Plate (sold separately)
